  • the display effect of the flexible crystal film screen installed on the stage
  • the effect of flexible crystal film display installed on the exterior wall of the hotel
  • shopping malls use flexible crystal film displays
  • the mall fence uses flexible crystal film display screens
  • the display effect of flexible crystal film display in the exhibition hall
  • the display effect of the flexible crystal film screen installed on the stage
  • the effect of flexible crystal film display installed on the exterior wall of the hotel
  • shopping malls use flexible crystal film displays
  • the mall fence uses flexible crystal film display screens
  • the display effect of flexible crystal film display in the exhibition hall

Flexible LED Film

LED Display Series: Transparent LED Display
Suitable Scene:Outdoor and Indoor

  • Transparency up to 90%, the picture is clear and transparent
  • High flexibility and can be customized into a variety of shapes
  • Lower power consumption and stronger energy saving effect

What is the Flexible LED Film?

The Flexible LED Film adopts LED lamp bead bare crystal ball planting technology, which places the LED lamp beads directly on the lamp board, reducing the frame of the cabinet so the weight is only one-fifth of the ordinary LED display screen.

The light board is made of transparent crystal film, with a transparent mesh circuit etched on the surface. After the components are mounted on the surface, a vacuum sealing process is performed to ensure that the circuit is not affected by dust or impurities.

Read More

Technical Data

VOLTAGE110 – 230 V
FREQUENCY50/60 Hz
MAX.POWER CONSUMPTION1000w
TEMPERATURE -10℃-60℃
CABINET WEIGHT1.3kg
BRIGHTNESS2000-4000cd/㎡
APPLICATION SCENARIOSOutdoor

Flexible LED Film Feature Introduce

flexible crystal film screens installed in shopping malls
01

High Transparency

The Flexible LED Film has a transparency rate of 90%, making it the most transparent display product except for holographic projection screens.

02

Strong Creativity

Flexible LED Films can match existing scenes, such as elevators, corridors, store glass, etc., to achieve various creative effects.

display effect of flexible crystal film screen installed in reception room
Flexible crystal screen mounted on shop glass
03

Wider Vision

The transparent nature of the Flexible LED Film allows for an unobstructed view of the audience, thereby expanding the audience’s understanding of promotional products and advertisements.

04

Easy To Install

The Flexible LED Film screen has a simple structure and is easy to install, providing more creative space for indoor and outdoor applications.

flexible crystal film screens installed in shopping malls

More Product Information

Model
P6
P6.25
P8
P10
P15
P20
Module size (mm)
816*384
1000*400
1000*400
1000*400
990*390
1000*400
LED light
REE1515
REE1515
REE1515
REE1515
REE2022
REE2022
Pixel composition
R1G1B1
R1G1B1
R1G1B1
R1G1B1
R1G1B1
R1G1B1
Pixel spacing (mm)
6*6
6.25*6.25
8*8
10*10
15*15
20*20
Module pixel
136*64=8704
160*40=6400
125*50=6250
100*40=4000
66*26=1716
50*20=1000
Pixel/m2
27777
25600
16500
10000
6625
2500
Brightness
2000/4000
2000/4000
2000/4000
2000/4000
2000/4000
2000/4000
Permeability
90%
90%
92%
94%
94%
95%
Angle of view °
160
160
160
160
160
160
Input voltage
AC110-240V50/
60Hz
AC110-240V50/
60Hz
AC110-240V50/
60Hz
AC110-240V50/
60Hz
AC110-240V50/
60Hz
AC110-240V50/
60Hz
Peak power
400w/㎡
600w/㎡
400w/㎡
400w/㎡
400w/㎡
400w/㎡
Average power
200w/㎡
200w/㎡
200w/㎡
200w/㎡
200w/㎡
200w/㎡
Work environment
Temperature
– 20~55
Humidity
10-90%
Temperature
– 20~55
Humidity
10-90%
Temperature
– 20~55
Humidity
10-90%
Temperature
– 20~55
Humidity
10-90%
Temperature
– 20~55
Humidity
10-90%
Temperature
– 20~55
Humidity
10-90%
Weight
1.3kg
1.3kg
1.3kg
1.3kg
1.3kg
1.3kg
Thickness
2.5mm
2.5mm
2.5mm
2.5mm
2.5mm
2.5mm
Drive mode
static state
static state
static state
static state
static state
static state
Control system
Nova/Colorlight
Nova/Colorlight
Nova/Colorlight
Nova/Colorlight
Nova/Colorlight
Nova/Colorlight
Typical value of life
100000H
100000H
100000H
100000H
100000H
100000H
Grayscale level
16bit
16bit
16bit
16bit
16bit
16bit
Refresh rate
3840 Hz
3840 Hz
3840 Hz
3840 Hz
3840 Hz
3840 Hz

Product Document Download

a flexible crystal film display in a company's showroom

Transparent as crystal, The flexible LED film makes the picture more realistic!

The flexible LED film  can make the displayed picture real and transparent, and the details can be easily seen at a glance.

the effect of flexible crystal film display mounted on the mall fence
How does flexible LED film work?

The crystal film screen installs LED lamp beads on a flexible film. A transparent mesh circuit is built into the film. When the lamp beads are powered on, it can produce stunning visual effects.

How are flexible LED film used?

As with ordinary LED display operations, first connect the power cord to the power socket, then turn on the switch, and you can start to replace the content of the flexible LED film screen.
