Types of P2.5 LED Panels
P2.5 Small Pitch LED panel is a type of LED panel with small pixel pitch. It is not only stable in performance, but also composed of LED displays that are still very clear when viewed from a close distance.
Designed and manufactured specifically for indoor environments, the P2.5 indoor LED panel is very stable, especially when playing video and moving pictures, with very high smoothness and excellent performance
P2.5 flexible LED panel is mainly used to create creative shapes or some places where conventional LED displays cannot be built. It adopts the concept of pre-maintenance design, which makes maintenance and installation more convenient and faster.
When we do not need to be fixed in one place for a long time, p2.5 rental LED panel gives us a better choice. It is very flexible in installation and removal, suitable for mobile use.
Advantages of P2.5 LED Panel
The pixel pitch of P2.5 LED panel is only 2.5mm, which can bring us high-definition picture quality, and can achieve the best viewing effect within a distance of 2-3 meters.
No matter how long or high the screen is, you basically can’t see any seam when splicing with P2.5 LED panel.
Whether it is hanging, wall-mounted, or column, it can be perfectly supported. This is a flexible installation method that other screens do not have.
Because the service life of P2.5 LED panels can be up to 10 years, you hardly need to think about maintenance and replacement during this period.
P2.5 LED Display Buying Tips
- Since the P2.5 LED panel contains tens of thousands of RGB LEDs, it is much more expensive than other models. The more RGB LEDs included in the panel, the higher the price, and you need to carefully consider the need and expense before purchasing.
- The difference in brightness and contrast will directly affect the viewing effect. If it is only used indoors and is not easily affected by sunlight, then choosing a brightness of around 1500 will suffice. If the installation is in a location that is susceptible to sunlight, then the brightness must be higher in order for the picture to remain unaffected. Otherwise, you may not be able to see the content of the screen because the brightness and contrast are too low.
- The p2.5 LED display can be easily built with a variety of different resolutions, but it should be noted that the higher the resolution, the higher the price will be.
- JYLED uses high quality LED beads for its P2.5 LED panels, which are durable and reliable, and usually do not need to worry about maintenance issues. However, if other more inferior products are chosen, then the maintenance may also be a considerable cost.
- LED display refresh rate can not be too low, if the use of too low refresh rate although cheap, but the viewing effect is very poor, for the glasses is not good, belong to the program of loss.
Application Scenarios for P2.5 LED Display Panels
Traditional conference rooms mainly use curtain projection, this way not only poor picture clarity, but also insufficient brightness, a little bit far away from the basic content can not see.
P2.5 LED panel screen clarity is very high, wide viewing angle, no matter which position you sit, you can clearly see the content.
When a hotel organizes a wedding, the P2.5 LED screen can play the happy photos of the bride and groom; when the birthday banquet is held, it can be replaced with birthday photos.
Therefore, P2.5 LED panel screen plays an important role in enhancing the atmosphere of the hotel and improving the excitement of diners.
P2.5 LED panel screens can be placed in public transportation areas such as airports, subways or stations as information dissemination boards. It can remotely change information in real time so that people will not miss any exciting current events.
In addition, it can also broadcast the weather condition in real time, which brings convenience for people’s traveling.
The P2.5 LED screen is able to show the objects of museums or exhibition halls in the form of digitization, which is eye-opening and brings unforgettable experience to the visitors while bringing rich experience.
P2.5 LED Display Panel Detailed Parameters
- Video
- Image
- LED Model
- LED Cabinet
- LED Control System
| LED Cabinet | |
| Model | P2.5 |
| Pixel pitch | 2.5mm |
| Pixel configuration | 1R1G1B |
| LED lamp | SMD2121 |
| Pixel matrix per panel | 64*64pixels |
| Module resolution rate | 64*64=4096dots |
| Module dimensions (W*H*D) | 160*160*13.0mm |
| Weight | 0.3kg±0.05kg |
| Package material | Polycarbonate |
| Construction | combined driver board |
| Input voltage | 4.8-5.5V |
| MAX. input current | 2.5A±0.1A |
| Driving mode | 1/32 scan, constant current |
| Module power | ≤12.5W |
| LED Cabinet | |
| Brightness | 800-1200 cd/m2 |
| Cabinet dimensions (W×H×D) | 480*480mm/640mmx640mm/800mmX800mm/960mmx960mm are avaliable. |
| Resolution ratio | 192*192=36864dots |
| Weight | 8.5±0.05 kg |
| Pixel density | 160,000dots/m2 |
| Viewing angle (H/V) | 140° Horizontal and Vertical |
| Best viewing distance | 2.5m-25m |
| LED Control System | |
| Gray scale per color | 12-16bits for red, green, blue |
| Colors | 16777216 |
| Lifetime | ≥100,000 hours |
| MTBF | ≥10,000 hours |
| Refresh rate | ≥ 720Hz |
| MAX. power | ≤488W/m2 |
| Input voltage (AC) | 110V ~ 240V |
| Operating temperature | -20°C ~+ 50°C |
| Operating humidity | 10% ~ 90% |
| Source compatibility (with video processor) | DVI/VGA,Video(multiple modes),RGBHV,composite Video Single,S-VIDEO,YPbPr(HDTV) |
| Software | Colorlight LEDVISION, Novastar NovaLCT, Linsn LEDStudio, and other brands of control systems can be chosen |
