Environmentally Friendly and Energy-Saving for Lower Operating Costs
The All-in-One LED display uses environmentally friendly and energy-saving LEDs as light sources, reducing power consumption while achieving optimal display effects, thus saving on operating costs.
This low-power display method also aligns with future sustainability goals, making a contribution to the environment.
Various Sizes for Freedom of Choice
Capable of displaying 4K resolution with lightweight and thin cabinets for easier installation.
This size is the most popular choice, with moderate pricing and excellent display performance.
Capable of displaying 4K HD resolution, matching the high-definition picture quality of 4K LCDs and offering seamless splicing capabilities that LCDs lack.
With a larger size while maintaining high-definition images, it increases display area for showcasing more visuals and content.
Advantages Of All-In-One LED Display Screen
With a minimalist and atmospheric ultra-narrow bezel design, the screen-to-body ratio reaches 95%. Equipped with wall-mounted brackets and omnidirectional wheels, it occupies less space and allows for displaying more content with its ultra-narrow bezels.
Built-in dual-channel audio output creates an immersive surround sound space. Users can adjust left or right channel audio output independently. With excellent audio decoding capabilities, it supports all audio formats on the market.
As we all know, if the viewing angle of many displays is incorrect, the picture will be blurry. The JYLED all-in-one LED display screen has a viewing angle of 170°, suitable for viewing from any angle.
The screen body of the JYLED all-in-one LED display screen is assembled before leaving the factory. After receiving the product, only assembly of other parts except the screen body according to one’s own needs is required for use.
Ultimate Visual Experience, Unforgettable
JYLED all-in-one LED display adopts 3-in-1 LED SMD technology, providing an ultimate visual experience that leaves a lasting impression on viewers.
Whether used in conference rooms or classrooms, it greatly enhances audience concentration, thus achieving the best presentation results.
Smart Management System for Simpler Content Control
Multiple input ports are integrated on the JYLED all-in-one LED display for easy connection with computers, phones, USB drives, and other peripherals, continuously outputting their contents.
The all-in-one LED display screen also includes a control management system internally, allowing users to easily set parameters and manage and play content without the need for additional software installation.
Simplified Structure, Lighter Weight
The manufacturer of the JYLED all-in-one LED display screen has restructured and optimized the entire screen body, further compressing the screen thickness to 39.8mm, 40% less than a conventional LED display of the same thickness.
The thinner and lighter screen not only improves the appearance, but also significantly reduces the weight of the entire screen body.
- All-in-One LED Display Parameter
| Title | All-in-One LED Display |
| Model | P1.5 |
| Pixel Pitch | 1.5mm |
| Screen Size | 106″,136″,163″,231″ |
| Screen Resolution | 4K |
| Pixel Density | 444,444 (dot/㎡) |
| Brightness | 700 nits |
| Scanning | 1/64S |
| Encapsulation Technology | SMD |
| Maintenance | Front and Rear |
| Installation | Wall Mount/Hanging Suspension/Floor Stand/Mobile Stand/etc. |
| Max. Power Consumption | 600w/m² |
| Average Power Consumption | 200w/m² |
| Cabinet Weight | 37kg |
| Cabinet Material | Aluminum |
| IP Rate | IP31 |
| Grayscale | 10000:1 |
| Refresh Rate | 3840Hz |
| Frame Change Frequency | 50/60Hz |
| Horizontal Viewing Angle | >140° |
| Vertical Viewing Angle | >140° |
| Best Viewing Distance | >1.5m |
| Input Voltage | Input Voltage AC110V – AC220V |
| Module Max. Current | 6.0-7.5 |
| Temperature-operating | ﹣10℃～60℃ |
| Humidity-operating | Humidity-operating 10%～90% |
| Life Span | ≥100,000h |
| MTBF | >10,000h |
Due to the weak waterproofing ability of all-in-one screens, outdoor use is generally not recommended. However, on clear nights, temporary outdoor use is possible.
As a professional LED display screen manufacturer, we can assist you with logo customization. Simply send us the logo you need to customize.
The sizes we produce are the most commonly used in the market. If you need larger or smaller sizes, you can communicate with us, and we will assess based on your requirements.
The display method of the all-in-one LED display screen is very flexible. Here are some common scenarios:
- Conference rooms
- Enterprises
- Shopping malls
- Hospitals
- Smart classrooms
- Control rooms
- Exhibitions
The commonly used control system is the Novastar control system, allowing the use of NovaLCT software for debugging.
